Introduction

In modern software development, APIs play a crucial role in connecting frontend applications with backend services. Writing API clients manually can be tedious and error-prone. This is where NSwagStudio comes in—a powerful tool for generating TypeScript clients, C# clients, and C# controllers from OpenAPI/Swagger definitions, saving time and ensuring consistency.

In this blog, we’ll walk through:

Let’s dive in!

Prerequisites for Using NSwagStudio

Before you start using NSwagStudio, ensure you have:

OpenAPI/Swagger Specification:

Your API must have an OpenAPI (formerly Swagger) definition in JSON or YAML format.

.NET SDK (if generating C# clients/controllers):

Install the .NET SDK for integrating with .NET applications.

Node.js (if generating TypeScript clients):

Required for frontend projects using Angular, React, or Vue.

NSwagStudio Installed:

Download it from https://github.com/RicoSuter/NSwag.

Types of Projects Where NSwagStudio is Useful

NSwagStudio can be used in various project types, including:

Frontend Applications

React, Angular, Vue.js: Generate a TypeScript client to make API calls without manually writing request logic.

Backend Applications

ASP.NET Core: Generate a C# client for consuming external APIs seamlessly.

Microservices Architecture: Simplifies communication between services by auto-generating client libraries.

Full-Stack Applications

When working on both frontend and backend, NSwagStudio helps keep API interactions consistent.

API-First Development

If you design APIs before implementation, NSwag can generate controllers, speeding up development.

Installing and Setting Up NSwagStudio

NSwagStudio is a GUI for NSwag, a popular API tooling library. You can install it from: https://github.com/RicoSuter/NSwag

Once installed, launch NSwagStudio, and you’ll see an interface below to load an OpenAPI/Swagger definition and generate clients or controllers.

Generate API Clients & Controllers in Minutes with NSwagStudio

Generating a C# Client

A C# client is useful for backend services that need to communicate with external APIs.

Step 1: Load the OpenAPI Specification

Open NSwagStudio.

In the Swagger Specification URL or File, enter the API definition URL or select a local JSON/YAML file.

Click “Create Local Copy” to parse the API definition.

Step 2: Configure C# Client Generation

  1. Under Output Type, select C# Client.
  2. Set the Class Name and Namespace.
  3. Choose HttpClient as the transport mechanism.
  4. Enable Use System.Text.Json for modern serialization.

Step 3: Generate and Integrate the C# Client

Click “Generate Outputs” or “Generate Files” and save the file in your .NET project.

Integration Steps in ASP.NET Core Project

  1. Add the generated C# client to your project.
  2. Register it as a service in Program.cs or Startup.cs:
builder.Services.AddHttpClient<ApiClient>(client =>
{
    client.BaseAddress = new Uri("https://api.example.com");
});

Inject and use the client in your services or controllers:

public class UserService
{
    private readonly ApiClient _apiClient;

    public UserService(ApiClient apiClient)
    {
        _apiClient = apiClient;
    }

    public async Task FetchUsersAsync()
    {
        var users = await _apiClient.GetUsersAsync();
        Console.WriteLine(users);
    }
}

Generating a C# Controller

If you have an OpenAPI definition but no backend implementation, NSwag can generate controllers for you.

Step 1: Load the OpenAPI Specification

Follow the same steps as before to load the OpenAPI definition.

Step 2: Configure C# Controller Generation

  1. Select C# Controller under Output Type.
  2. Set Namespace and Class Name.
  3. Choose ASP.NET Core Web API as the framework.
  4. Enable Use System.Text.Json if needed.

Step 3: Generate and Integrate the C# Controller

Click “Generate Outputs” or “Generate Files” and save the file in your ASP.NET Core project.

Step 4.1 Modify Program.cs (or Startup.cs in older versions)

builder.Services.AddHttpClient<ApiClient>(client =>
{
    client.BaseAddress = new Uri("https://api.example.com/");
})
.ConfigureHttpClient((sp, client) =>
{
    // Optional: dynamic logic from services
})
.AddHttpMessageHandler(() => new AuthHeaderHandler("your-token-here"));

Step 4.2: Create a DelegatingHandler for Adding Auth Header

public class AuthHeaderHandler : DelegatingHandler
{
    private readonly string _token;

    public AuthHeaderHandler(string token)
    {
        _token = token;
    }

    protected override async Task<HttpResponseMessage> SendAsync(HttpRequestMessage request, CancellationToken cancellationToken)
    {
        if (!string.IsNullOrEmpty(_token))
        {
            request.Headers.Authorization = new AuthenticationHeaderValue("Bearer", _token);
        }

        return await base.SendAsync(request, cancellationToken);
    }
}

If You Use an ApiKey Instead of Bearer Token

request.Headers.Add("X-API-KEY", "your-api-key");

Conclusion: Save Time, Reduce Errors, and Automate API Integration

NSwagStudio significantly simplifies API integration by automating client and controller generation. Whether you’re working with TypeScript, C#, or ASP.NET Core, it ensures consistency, saves time, and reduces errors.

By registering generated clients globally with Dependency Injection and following clean integration patterns, you create a maintainable and scalable codebase.

✅ Save development hours
✅ Ensure type safety and consistency
✅ Simplify collaboration between teams

Don’t waste time writing what NSwag can generate in seconds.

Start using NSwagStudio today and bring speed, structure, and sanity to your API development workflow!

👉 If you found this guide helpful, share it with your team – and explore the full potential of automated API tooling.
